Spectra Energy

DCDB BOX-1-3 KW 1 MPPT -1 IN 1 OUT -1 PHASE

DCDB BOX-1-3 KW 1 MPPT -1 IN 1 OUT -1 PHASE

Regular price Rs. 3,600.00
Regular price Rs. 5,000.00 Sale price Rs. 3,600.00
Sale Sold out
Tax included.
Size

 DCDB BOX- 1-3 KW 1 MPPT -1 IN 1 OUT -1 PHASE

 DCDB box is a component of an electricity supply system which divides an electrical power feed into subsidiary circuits, which provides a protective fuse or circuit breaker for each circuit.  DCDB controls the DC power from solar panel and with having necessary surge protection device (SPD) and fuses and if necessary MCB also for Single Phase.

A solar DCDB is a system which controls the direct current coming from the solar panels. If anything goes wrong at the solar panel side, it will give protection to the equipment and prevent it from damage. This system primarily protects solar panel strings and the solar inverter.

Benefits: A DCDB box contains a DC SPD to protect against surges, a DC MCB, and a fuse that breaks the circuit in case of high voltages.

Product Name: DCDB BOX - 1-3 KW 1 MPPT -1 IN 1 OUT -1 PHASE

Brand: Spectra

Product Type: DCDB BOX

Product Model: 1-3 KW MPPT 1 PHASE

Material: Copper, Polycarbonate

MPPT: 1

Color: White Transparent

Power: 1-3kw

Shape: Rectangular

Current: 16A

Is It Waterproof: Waterproof

Max.Voltage Rating: 1000V

Number of Strings: 1 in 1 Out

Warranty: 5 Years

Operating Conditions Temp: 40 Degree C

Usage/Application: Solar Application

Dimension: 180(L) x 180(W) x 100(H) mm

Weight: 3 Kg

Country of Origin: India

Certificate: Not Applicable

Packing: Standard Packing

Delivery: 14 Days (Max)

Return Policy: Returns Not Accepted (Unless products has any Damage)

Minimum Order Quality (MOQ): (Pack of 1)

Available for Export Order: Yes
