Luminous Charge Retrofit Shine 2420

Luminous Charge Retrofit Shine 2420

Solar Retrofit is an upgrade of Charge controllers which when connected to any existing UPS converts it into 100% Solar UPS without any change in electrical wiring of existing UPS. It has inbuilt intelligence to maximise use of solar energy to power your appliances.

   Luminous Solar Retrofit uses the Solar Optimization technique to extract minimum power from the mains and instead use solar energy to the maximum, for example if the battery is charged by only 70% till dusk the Solar Retrofit after analyzing the usage pattern will not charge the battery through the mains but will wait until dawn to do so, hence saving the electricity bill and optimizing the use of ecofriendly solar energy.

Luminous Solar Retrofit 20Amps @ 12V/24V Shine SRS 2420 is an upgraded version of Solar PWM Charge Controller which converts conventional Inverter into hybrid solar system.

Product Name: Luminous Charge Retrofit Shine 2420

Brand: Luminous

Product Type: Retrofit

Product Model: Shine 2420

VA Rating: 20A@12v/24v

Charging Current: 20 Amps

Charge Controller Type: PWM

Technology (Solar): With Battery

Max.supported panel power (Wp): 400Wp@12v, 800Wp@24v

Warranty: 1 Year (12 months)

Usage/Application: Homes & Small Shops

Dimension: 17.8(L) x 15.9(W) x 7.1(H) Cm

Weight: 1.2 Kg

Country of Origin: India

Certificate: Not Applicable

Packing: Standard Packing

Delivery: 14 Days (Max)

Return Policy: Returns Not Accepted (Unless products has any Damage)

Minimum Order Quality (MOQ): (Pack of 1)

Available for Export Order: Yes
